| Наименование марки: | KHJ |
| Номер модели: | DN63808 |
Description
DN63808 is a high-performance acrylic foam double-sided tape made with a special adhesive formula,gray in color.The special adhesive system delivers excellent adhesion to many painted surfaces and metals.
Construction
Features
● Exceptional adhesion, suitable for metal, glass and certain plastics and painted surfaces.
● Strong resistance to both static and dynamic stress, capable of withstanding certain levels of shock and vibration.
● Superior aging resistance, capable of enduring high and low temperatures, UV exposure, moisture, and solvents.
Application
● Automotive Industry, Electronics Industry, Advertising Industry Hardware Manufacturing.
● Construction Industry, Solar PV Industry, Elevator Applications.
Technical Date
| Test Item | Test Value | Test Method | |
| Total thickness (Liner removed) | 0.8mm | Micrometers | |
| 90°Peel strength to steel (20min) | 19N/cm | GB/T2792-2014 | |
|
Static Shear Strength (24mm*24mm,23℃,1000g) |
10000mins | GB/T4851-2014 | |
| Temperature Resistance (℃) | Short term | 150 |
/ |
| Long term | 93 | ||
Shelf Life
● Optimal Storage Conditions: Temperature 21℃, Relative Humidity 50% RH.
● Shelf life: 12 months from the date of manufacture when stored in initial packing.
Application Guidelines
The ideal application temperature range is 20℃-40℃(68°F-104°F),Application of the tape to substrates should be avoided at temperature below 10℃.
Notice
Keep the product away from heat sources and open flames.
Surfaces to be bonded must be clean,dry,and free from oil,grease,or other contaminants.
